Technical specifications
PANEL SIZES:
Standard is nominal 2'x2'.
Optional are nominal 1'x1' to 4'x4'.
BEAM:
0.024" thick Galvanized Steel or Aluminum as Req'd.
FINISHES:
Standard are White, Black, or Satin Silver.
Custom Painted are Polyurethane Epoxy.
Mirrored are Polished Brite.
Wood Grains are Premo Laminate and Woody Powder Coated Finishes.
PLENUM:
8" recommended minimum.
FIRE CODE:
Non-Combustible. (ASTM E-84).
MATERIAL:
Cell: 0.020" thick Aluminum.
Beam: 0.024" thick Galvanized Steel or Aluminum as Req'd.
(Contact Factory for full Architectural Specification.)
INSTALLATION
