Technical Specifications
LOUVER SIZES:
Standard is 2' wide x 6' long.
Optional are 2' wide x 4' long through 4' wide x 8' long.
Custom Configurations Available -- Contact Factory.
PLENUM:
8" Minimum.
FINISHES:
Standards are Mastic White, Anodized PXL, or GunMetal.
Custom painted are polyurethane epoxy.
Mirrored/Brushed/Etc. are Anodized.
CELL SIZES:
Standards are 6",8",12" or 16".
Custom Cell Spacing Available -- Contact Factory.
FIRE CODE:
Class 1 Material (ASTM E84).
MATERIAL:
1/8" thk. Extruded Aluminum.
LEEDs:
Up to 90% Recycled Content.
