Technical specifications
PANEL SIZES:
Standard widths are 12", 16", 20", and 24".
Standard length is 11'.
Other Configurations Available -- Contact Factory.
FINISHES:
Standard metal are White, Satin Silver, or Gun Metal.
Custom Painted are Polyurethane Epoxy.
Wood Grains are Premo Laminate and Woody Powder Coated Finishes.
FIRE CODE:
Panel is Class 1 Material per ASTM-E84.
Seismic T-Bar Suspension available upon request.
MATERIAL:
Interior Duty from 0.032" to 0.040" thk. Aluminum.
Exterior or Heavy Duty from 0.050" to 0.063" thk. Aluminum.
Standard Carrier is 0.040" thk. Aluminum.
LEEDs:
Up to 90% for Aluminum Pans & Carrier.
Installation
