Technical specifications
PANEL SIZES:
Standard is 42" wide by 96" or 120" lengths. Other sizes available.
PROFILE:
ADC offers 20 different Profiles. See Profile sheets for specifications.
FINISHES:
Standards are Mastic White, Baron Ivory, Victorian Gray, or Mill Finish.
Custom painted are polyurethane epoxy.
Mirrored/Brushed are polished brite.
Wood Grains are Premo Laminate and Woody Powder Coated Finishes.
PERFORATION:
Standard is 1/8" holes on 21/64" staggered centers, 14% open area.
INSULATION:
Standard is 2" thk., sealed in black poly bag. Other thicknesses available.
FIRE CODE:
Class 1 Material (ASTM E84)
MATERIAL:
Aluminum or galvanized steel. See Profile sheets for appropriate thickness.
LEEDs:
Up to 90% Recycled Content (Aluminum).
Installation
