Technical specifications
UNIT SIZES: Standard Widths by Depths are 4"x 4"; 4"x 6"; 6"x 6"; 6"x 9"; & 9"x 9." Standard Length is 1 0.' Custom Sizes Available.
FINISHES: Standards are Mastic White. Anodized PXL or Gun Metal. Custom painted are polyurethane epoxy. Mirrored/Brushed are polished brite.
DIFFUSER: Standard is white translucent fabric. Optional translucent polycarbonate..
FIRE CODE: Class 1 Material (ASTM E84).
MATERIAL: .040" thk. (min.) Aluminum (Leeds 70% recylced). 20 gauge galvanized steel (Leeds 15% recylced).
INSTALLTION
