Technical specifications
PANEL SIZES: Standard are 2'x 2'; 2'x 4'; 1 'x 4'; and 3'x 3'. Custom Sizes: 1' x 1' upto 4' x 4' available.
FINISHES: Standard metal are White, Satin Silver, or Gun Premo Metal. Wood Custom Laminate Painted are are Maple, Cherry, polyurethane and epoxy. Walnut.
PLENUM: 4" recommended w/o HVAC or lights 12" recommended w/HVAC or lights.
FIRE CODE: Panel is Class 1 Material per ASTM-E84.
MATERIAL: Recommended for Panels upto 2' wide = 3' wide = .040" thk. aluminum, 4' wide .050" thk. aluminum. T-Bar Suspension = .021" thk. galvan'd steel (stnd) or .024" thk (heavy duty).
LEEDs: Upto 90% for aluminum panel, 20% galvanized.
INSTALLTION
